Cuplock Scaffolding System
Created with Pixso.

High Load Capacity Cuplock Scaffolding System Painted / Galvanized Modular Scaffold System

High Load Capacity Cuplock Scaffolding System Painted / Galvanized Modular Scaffold System

Brand Name: WKS
MOQ: 200/Piece
Price: US $8.90 - 12.00/ Piece
Payment Terms: T/T
Supply Ability: 1000 piece in 10 days
Detail Information
Product Description
Detail Information
Place of Origin:
Hebei,China
Certification:
ROHS
Product Name:
Cuplock Scaffolding System
Thickness:
3.0/3.25mm
Diameter:
48mm
Quality Guarantee:
2 Year
Peculiarity:
Easy Assembling
Surface Treatment:
Painted/Galvanized
Colour:
Customized Colour
Technology:
CO2 Arc Welded
Dimension:
1200,1800,2400mm Or As Your Request
Customize Or Not:
Available In Custom Or Standard Sizes
Packaging Details:
Bundled / Tied in bundles/Optimization of container loading
Highlight:

High Load Capacity Cuplock Scaffolding System

,

Painted Modular Scaffold System

,

Galvanized Modular Scaffold System

Product Description
Cuplock Scaffolding with Steel Plank and Guardrail for Safe Working Platform
Cuplock Scaffolding is a heavy-duty modular scaffolding system featuring a patented cup-lock connection. Designed for commercial construction, bridge work, and formwork support, it provides superior load capacity and stability for high-rise projects and industrial applications requiring safe, efficient access platforms.
Features & Functions
  • Cup-Lock Quick Connection: Horizontal ledgers lock into vertical standards with a twist of the top cup, enabling rapid tool-free assembly without nuts or bolts. This speeds up construction and reduces labor costs.
  • High Load Capacity: Engineered to support heavy loads from materials, equipment, and workers, making it ideal for concrete pouring support, masonry work, and large facade installations.
  • Stable Grid Structure: Uniform 500mm or 1000mm node spacing creates a rigid, wobble-free platform that ensures worker safety and stability at significant heights.
  • Modular Flexibility: Components are easily configurable for straight walls, towers, and large-area decks, adapting efficiently to various project layouts and complex structures.
Key Specifications
  • Material: Q235 or Q345 Steel
  • Standard Tube: 48.3mm Outer Diameter
  • Wall Thickness: 2.75mm to 3.2mm
  • Node Spacing: 500mm or 1000mm
  • Load Capacity: Up to 4.5 kN/m²
  • Surface: Hot-Dip Galvanized
Competitive Advantages
  • Fast Assembly & Dismantling: The cup-lock mechanism allows quicker setup and teardown than traditional tube-and-coupler systems, reducing project timelines and labor expenses.
  • Enhanced Safety & Stability: The rigid grid structure and secure connections minimize platform movement, providing a safer working environment for high-altitude tasks.
  • Cost-Effective Reusability: High durability and minimal component loss ensure long service life and low maintenance, offering excellent return on investment for rental companies and contractors.
High Load Capacity Cuplock Scaffolding System Painted / Galvanized Modular Scaffold System 0
Product Parameters
Standards (Uprights)
Item No. Length Weight Picture
BSCS 300 3m/9'10" 17.5kg/38.25 Ibs High Load Capacity Cuplock Scaffolding System Painted / Galvanized Modular Scaffold System 1
BSCS 250 2.5 m/8'2" 14.57 kg/32.12 Ibs
BSCS 200 2m/6'2" 11.82 kg/26.07 Ibs
BSCS 150 1.5 m/4'11" 9.05 kg/19.95 Ibs
BSCS 100 1 m/3'3" 6.3 kg/13.91 Ibs
BSCS O50 0.5m/1'8" 3.5 kg /7.77 Ibs
Ledgers (Horizontal Braces)
Item No. Length Weight Picture
BSCL 250 2.5 m/8'2" 9.35 kg/20.61 Ib High Load Capacity Cuplock Scaffolding System Painted / Galvanized Modular Scaffold System 2
BSCL 180 1.8 m/6' 6.85 kg / 15.1 Ibs
BSCL 150 1.5 m/4'11" 5.75 kg/9.46 Ibs
BSCL 120 1.2m/4 4.29 kg/13.91 Ibs
BSCL 090 0.9m/3' 3.55 kg /7.83 Ibs
BSCL 060 0.6m/2' 2.47 kg / 5.45 Ibs
Our Services
  • Customized Production Services: Professional engineering team provides detailed product application solutions based on your project drawings.
  • Timely Response Service: Professional engineers available before, during, and after sales to promptly solve and meet your needs.
  • Worry-Free After-Sales Service: One-on-one service teams to help complete implementation and landing of engineering projects.
Frequently Asked Questions
Are you a trading company or a manufacturer?
We are a subsidiary foreign trade company of a group company, responsible for operating export business of formwork and scaffolding products. Our group has two major production bases with over 20 years of production experience.
How can I get a quotation?
For simple projects with your own engineer, provide a bill of materials. For complex projects like apartments and residences, our consultants will develop an application plan based on your engineering drawings.
How long does it usually take to complete the plan and quotation?
Generally 5-8 days to complete specific plans and detailed quotations.
Can you provide free samples?
Yes, we can provide samples. You will need to pay for the shipping cost.
How long is the estimated delivery time after the contract is signed?
Usually 30-60 days depending on project complexity. More accurate delivery times are provided during planning.
Is the plastic template prone to deformation?
In long-term high temperature environments, slight deformation may occur. We recommend aluminum alloy formwork or steel frame wood formwork for high temperature areas.
What are the defects of the plastic template system?
Limited load capacity for large-sized concrete structures and poor high temperature resistance with potential deformation in high-temperature areas.
What is the payment method you require?
Payments ≤1,000USD: 100% in advance. Payments ≥10,000USD: 30% T/T in advance, balance before shipment. L/C also accepted.
High Load Capacity Cuplock Scaffolding System Painted / Galvanized Modular Scaffold System 3
