Cuplock Scaffolding System
Created with Pixso.

Hot Dip Galvanised Scaffolding High Strength Steel Scaffolding Systems Flexible

Hot Dip Galvanised Scaffolding High Strength Steel Scaffolding Systems Flexible

Brand Name: WKS
MOQ: 200/Piece
Price: US $8.90 - 12.00/ Piece
Payment Terms: T/T
Supply Ability: 1000 piece in 10 days
Detail Information
Product Description
Detail Information
Place of Origin:
Hebei,China
Certification:
ROHS
Product Name:
Galvanised Scaffolding
Surface Treatment:
Painted/Galvanized
Colour:
Customized Colour
Diameter:
48mm
Thickness:
3.0/3.25mm
Dimension:
1200,1800,2400mm Or As Your Request
Quality Guarantee:
2 Year
Peculiarity:
Easy Assembling
Technology:
CO2 Arc Welded
Customize Or Not:
Available In Custom Or Standard Sizes
Packaging Details:
Bundled / Tied in bundles/Optimization of container loading
Highlight:

Hot Dip Galvanised Scaffolding

,

High Strength Steel Scaffolding Systems

,

Steel Scaffolding Systems Flexible

Product Description
Hot Dip Galvanized Cuplock Scaffolding for Bridge and Tunnel Construction
Product Overview
Cuplock Scaffolding is a high-load modular system renowned for its hammer-driven cup-lock mechanism. It bridges the gap between basic frame scaffolding and complex ringlock systems, offering superior strength and faster assembly for medium to large-scale construction, industrial maintenance, and heavy formwork support.
Features & Functions
  • Hammer-Lock Assembly: Vertical standards feature fixed cups at 500mm intervals. Horizontal ledgers slot in and are secured by a rotating upper cup with a single hammer blow, eliminating nuts, bolts, and loose couplers for rapid, tool-light erection.
  • High Load Bearing: Engineered for heavy-duty applications, the rigid node points create a stable structure capable of supporting significant vertical loads, making it ideal for shoring and concrete pouring operations.
  • Modular Flexibility: The 500mm grid spacing on standards allows for precise height adjustments and versatile configurations, including straight runs, stair towers, and basic curved structures.
  • Minimal Loose Parts: The integrated locking system drastically reduces the number of small loose components, lowering the risk of loss on site and simplifying inventory management.
Key Specifications
  • Material: High-Strength Steel (Q235 / Q345 equivalent)
  • Tube: 48.3mm Outer Diameter, Wall Thickness 3.2mm - 4.0mm
  • Standard Lengths: 0.5m, 1.0m, 1.5m, 2.0m, 2.5m, 3.0m
  • Bay Sizes: Common widths 0.9m, 1.2m, 1.5m, 1.8m
  • Load Capacity: Up to 55 kN per standard (depending on configuration)
  • Finish: Hot-Dip Galvanized (HDG) for maximum corrosion resistance
Competitive Advantages
  • Faster Than Tube & Coupler: Assembly is up to 50% faster than traditional systems, significantly reducing labor costs and project timelines.
  • Stronger Than Frame Scaffolding: Offers a higher load capacity and greater rigidity than standard frame systems, suitable for more demanding industrial and shoring tasks.
  • Cost-Effective Versatility: Provides the strength needed for heavy loads with the simplicity and reusability that keeps long-term ownership costs low compared to more complex systems.
Hot Dip Galvanised Scaffolding High Strength Steel Scaffolding Systems Flexible 0
Product Parameters - Standards (Uprights)
Item No. Length Weight Picture
BSCS 300 3m/9'10" 17.5kg/38.25 Ibs Hot Dip Galvanised Scaffolding High Strength Steel Scaffolding Systems Flexible 1
BSCS 250 2.5 m/8'2" 14.57 kg/32.12 Ibs
BSCS 200 2m/6'2" 11.82 kg/26.07 Ibs
BSCS 150 1.5 m/4'11" 9.05 kg/19.95 Ibs
BSCS 100 1 m/3'3" 6.3 kg/13.91 Ibs
BSCS O50 0.5m/1'8" 3.5 kg /7.77 Ibs
Product Parameters - Ledgers (Horizontal Braces)
Item No. Length Weight Picture
BSCL 250 2.5 m/8'2" 9.35 kg/20.61 Ib Hot Dip Galvanised Scaffolding High Strength Steel Scaffolding Systems Flexible 2
BSCL 180 1.8 m/6' 6.85 kg / 15.1 Ibs
BSCL 150 1.5 m/4'11" 5.75 kg/9.46 Ibs
BSCL 120 1.2m/4 4.29 kg/13.91 Ibs
BSCL 090 0.9m/3' 3.55 kg /7.83 Ibs
BSCL 060 0.6m/2' 2.47 kg / 5.45 Ibs
Our Services
  • Customized Production Services: Professional engineering team provides detailed product application solutions based on your project drawings.
  • Timely Response Service: Professional engineers available before, during, and after sales to promptly solve and meet your needs.
  • Worry-Free After-Sales Service: One-on-one service teams to help complete implementation and landing of engineering projects.
Frequently Asked Questions
Are you a trading company or a manufacturer?
We are a subsidiary foreign trade company of a group company, responsible for operating export business of formwork and scaffolding products. Our group has two major production bases with over 20 years of production experience.
How can I get a quotation?
For simple projects with your own engineer, provide a bill of materials. For complex projects like apartments and residences, our consultants will develop an application plan based on your engineering drawings.
How long does it usually take to complete the plan and quotation?
Generally 5-8 days to complete specific plans and detailed quotations.
Can you provide free samples?
Yes, we can provide samples. You will need to pay for the shipping cost.
How long is the estimated delivery time after the contract is signed?
Usually 30-60 days depending on project complexity. More accurate delivery times are provided during planning.
Is the plastic template prone to deformation?
In long-term high temperature environments, slight deformation may occur. We recommend aluminum alloy formwork or steel frame wood formwork for high temperature areas.
What are the defects of the plastic template system?
Limited load capacity for large-sized concrete structures and poor high temperature resistance with potential deformation in high-temperature areas.
What is the payment method you require?
Payments ≤1,000USD: 100% in advance. Payments ≥10,000USD: 30% T/T in advance, balance before shipment. L/C also accepted.
Hot Dip Galvanised Scaffolding High Strength Steel Scaffolding Systems Flexible 3
