High Strength Aluminum Frame Formwork Corrosion Resistant Aluminium Formwork Panels Lightweight

High Strength Aluminum Frame Formwork Corrosion Resistant Aluminium Formwork Panels Lightweight

Brand Name:	WKS
MOQ:	50 piece
Price:	US $97.00 - 130.00/ Square Meter
Payment Terms:	T/T
Supply Ability:	1000 piece in 10 days

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei,China

Certification:

ROHS

Product Name:

Aluminum Frame Formwork

Material:

Aluminum

Coating Of Aluminum Frame:

Powder Coating

Maximum Concrete Pressure:

60kN/sqm

Max Size Of Slab:

Plywood Panel Material 1800mm*2400mm

Max Size Of Wall&Column:

1000mm*3000mm

Aluminum Frame Height:

100mm/120mm

Aluminum Frame Material:

6061-T6

Plywood Panel Material:

Birch,poplar,eucalyptus,mixed Or Plastic Plywood

Plywood Panel Thickness:

12mm/15mm/18mm

Packaging Details:

Bundled / Tied in bundles/Optimization of container loading

Highlight:

High Strength Aluminum Frame Formwork

Aluminum Frame Formwork Corrosion Resistant

Aluminium Formwork Panels Lightweight

Product Description

High Strength Aluminum Frame Formwork For Large Scale Infrastructure Projects

Aluminum Frame Formwork: Lightweight & High-Strength Modular Shuttering

The Aluminum Frame Formwork is a hybrid construction system combining a rigid 6061-T6 aluminum alloy frame with a replaceable film-faced plywood panel. Designed for cast-in-place concrete walls, slabs, and columns, it offers the durability of metal with the cost flexibility of timber, making it ideal for mid-to-high-rise residential and commercial projects.

Key Features & Functional Benefits

Lightweight & Labor-Saving: At only ~25 kg/m², panels are easy to handle manually, reducing crane dependency and accelerating on-site assembly with simple pin-and-wedge connections.
High Load Capacity: Engineered to withstand fresh concrete pressures up to 60 kN/m², ensuring structural stability and dimensional accuracy during pouring.
Hybrid Economy: The long-life aluminum frame (200+ reuses) paired with replaceable plywood panels offers a lower total cost of ownership compared to all-steel systems, with minimal maintenance.

Technical Specifications

Frame Material: 6061-T6 Aluminum Alloy (Yield Strength ≥240 MPa)
Panel Face: 15mm / 18mm High-Density Film Faced Plywood (Phenolic Coated)
Standard Sizes: Widths 300mm-1200mm; Heights 2400mm, 2700mm, 3000mm
Surface Treatment: Powder-coated frame for enhanced corrosion resistance

Detailed Technical Specifications

No	Item	Data
1	Weight	≈24kg/sqm
2	Plywood Panel Thickness	12mm/15mm/18mm
3	Plywood Panel Material	Birch, poplar, eucalyptus, mixed or Plastic plywood
4	Aluminum Frame Material	6061-T6
5	Aluminum Frame Height	100mm/120mm
6	Max Size of Wall & Column	1000mm*3000mm
7	Max Size of Slab	1800mm*2400mm
8	Maximum Concrete Pressure	60kN/sqm
9	Coating of aluminum frame	Powder coating

Competitive Advantages

Superior Cost Efficiency: Despite a higher initial investment, its long lifespan, low maintenance, and reduced labor requirements offer the lowest total cost of ownership for repetitive projects.
Optimal Lifecycle ROI: Offers the best balance of initial cost, high reusability (frames last for hundreds of cycles), and low operational expense, outperforming both steel and wood in repetitive projects.
Labor & Time Savings: The lightweight design and pin-and-wedge connection system significantly reduce erection and stripping time compared to traditional formwork.
Zero Waste & High Scrap Value: Aluminum frames are 100% recyclable at end-of-life, providing substantial residual value and supporting sustainable construction practices.
Optimized for Speed: The lightweight design and quick-connect system are specifically engineered to achieve fast floor cycles (e.g., 4-5 days per floor), reducing overall project duration.
High Residual Value: Aluminum retains significant scrap value at end-of-life, providing a financial return that wood or plastic systems cannot match.
Advanced production equipment and 20 years of production experience
Experienced engineering team with an average of about 10 years of experience ensures smooth project progress
Full cycle project services to ensure smooth application of aluminum frame formwork

One Stop Solution Service Process

Free Consultation Service You provide us with construction drawings to evaluate which formwork system solution is more cost-effective and provide a detailed quotation list for you.
Full Process One-on-One Project Team Service Each project will have an independent team to provide you with professional engineering solution services, business communication services, and on-site construction management services.
Project Emergency Plan Service The project scheme formulation process will cautiously consider the emergency handling of aluminum alloy formwork system products during use.

Frequently Asked Questions

Do you provide samples? Is the sample chargeable or free?

Yes, we can provide small size samples. If you need big size samples, you need to pay for them. You will also need to pay for the shipping cost.

Are you a trading company or a manufacturer?

We are a subsidiary foreign trade company of a group company, mainly responsible for operating the export business of formwork and scaffolding products. Our group company has two major production bases, specializing in the production and processing of formwork and scaffolding products for over 20 years.

How to get quotation?

For simple concrete pouring projects with your own engineer, provide us with a bill of materials for quotation. For complex projects like apartments and residences, our professional consultants will develop an application plan based on your engineering architectural drawings and provide a quotation.

What can we supply for you?

A comprehensive range of scaffolding, formwork accessories and safety products for the construction industries. We also design and produce steel items as per client requests, providing all kinds of scaffolding for your needs.

How can you guarantee that we will get better service and high quality products?

Advanced automated production lines, experienced workers, quality inspection teams, and chemical/physical laboratories ensure high quality products. Our engineering team provides technical support and our sales team offers one-on-one business communication through various platforms.

How long is the estimated delivery time after the contract is signed?

According to project complexity, it usually takes 30-60 days to complete stocking. We provide more accurate delivery time estimates during the planning and quotation process.

What is your terms of payment?

T/T 30% deposit payment before manufacture, and 70% balanced payment against B/L Copy. Or L/C.
