High Strength Aluminum Frame Formwork Reusable Adjustable Column Formwork

Aluminum Frame Formwork is a lightweight, high-strength modular system engineered for fast-cycle concrete construction in high-rise residential and commercial projects. It combines extruded aluminum alloy frames with replaceable panels to deliver exceptional efficiency and precision.

• Lightweight & Easy Handling: Significantly lighter than steel systems (approx. 25-30 kg/m²), it enables manual handling and faster installation without heavy cranes, reducing labor fatigue and equipment costs.
• Fast Assembly with Pin & Wedge: Utilizes a simple pin-and-wedge connection system for rapid locking of panels, allowing for quick setup and dismantling, which accelerates project timelines.
• High Precision & Smooth Finish: The rigid aluminum frame ensures minimal deflection, producing consistently smooth concrete surfaces that often eliminate the need for plastering.
• Corrosion Resistant: Naturally resistant to rust and corrosion, it performs reliably in various climates and requires minimal maintenance compared to steel.

• Frame Material: 6061-T6 / 6082-T6 Aluminum Alloy
• Panel: 15mm / 18mm Film Faced Plywood or Composite
• Standard Sizes: 600x2400mm, 900x2400mm, 1200x2400mm
• Max Concrete Pressure: 60 - 70 kN/m²
• Reuse Cycles: 200+ cycles (frames), 30-50 cycles (panels)

• Superior Cost Efficiency: Despite a higher initial investment, its long lifespan, low maintenance, and reduced labor requirements offer the lowest total cost of ownership for repetitive projects.
• Optimal Lifecycle ROI: Offers the best balance of initial cost, high reusability (frames last for hundreds of cycles), and low operational expense, outperforming both steel and wood in repetitive projects.
• Labor & Time Savings: The lightweight design and pin-and-wedge connection system significantly reduce erection and stripping time compared to traditional formwork.
• Zero Waste & High Scrap Value: Aluminum frames are 100% recyclable at end-of-life, providing substantial residual value and supporting sustainable construction practices.
• Optimized for Speed: The lightweight design and quick-connect system are specifically engineered to achieve fast floor cycles (e.g., 4-5 days per floor), reducing overall project duration.
• High Residual Value: Aluminum retains significant scrap value at end-of-life, providing a financial return that wood or plastic systems cannot match.
• Advanced production equipment and 20 years of production experience
• Team of engineers with an average of about 10 years of experience ensures smooth project progress
• Full cycle project services to ensure smooth application of aluminum frame formwork

• Free Consultation Service: You provide us with construction drawings to evaluate which formwork system solution is more cost-effective and provide a detailed quotation list for you.
• Full Process One-on-One Project Team Service: Each project will have an independent team to provide you with professional engineering solution services, business communication services, and on-site construction management services.
• Project Emergency Plan Service: The project scheme formulation process will cautiously consider the emergency handling of aluminum alloy formwork system products during use.
