Film Faced Plywood
Created with Pixso.

1250*2500 Birch Film Faced Plywood Waterproof Heavy Duty Plywood Weather Resistant

1250*2500 Birch Film Faced Plywood Waterproof Heavy Duty Plywood Weather Resistant

Brand Name: WKS
MOQ: US $7.50 - 10.80/ Piece
Price: US $55.00 - 70.00/ Square Meter
Payment Terms: T/T
Supply Ability: 1000 piece in 10 days
Detail Information
Place of Origin:
Hebei,China
Certification:
ROHS
Product Name:
Birch Film Faced Plywood
Moisture Content:
6-12%
Gluetype:
Melamine Urea Formaldehyde (MUF) Or Phenolic Resin Adhesive
Density:
Around 520 Kg/m3
Coretype:
Poplar, Eucalyptus, Or Other Hardwood Cores
Thickness:
Typically Ranges From 12mm To 25mm
Size:
Standard Size 1220mm X 2440mm (4ft X 8ft)
Specification:
1250*2500 (customized Size)
Layers:
3/5/7/9/11/13/15/18 Layers
Weight:
Varies Depending On Thickness And Core Material
Packaging Details:
Bundled / Tied in bundles/Optimization of container loading
Highlight:

1250*2500 Birch Film Faced Plywood

,

Birch Film Faced Plywood Waterproof

,

Heavy Duty Plywood Weather Resistant

Product Description
Birch Film Faced Plywood For Heavy Duty Shuttering And Structural Support
Film Faced Plywood: High-Reuse Concrete Formwork Panel

Film Faced Plywood is a structural shuttering panel engineered for high-rise buildings and civil projects. Composed of hardwood veneers bonded with WBP phenolic glue and coated with a phenolic film, it delivers a smooth concrete finish and exceptional durability under repeated use.

Key Features & Functions
  • Superior Concrete Release: The dense phenolic film creates a non-stick surface that prevents concrete adhesion, ensuring smooth, defect-free walls and slabs with minimal cleaning effort.
  • High Strength & Reusability: Birch or eucalyptus core construction offers excellent load-bearing capacity. Panels withstand 10-30+ pours depending on grade, significantly reducing cost per use.
  • Waterproof & Weather Resistant: Full WBP glue bonding and sealed edges protect against moisture absorption, preventing delamination and swelling even in harsh outdoor conditions.
Technical Parameters
  • Sizes: 1220x2440mm, 1250x2500mm, 1525x3050mm (custom sizes available)
  • Thickness: 12mm, 15mm, 18mm, 21mm (standard construction range)
  • Core & Film: Birch/Hardwood core; Black, Brown, or Red phenolic film (120-220g/sqm)
  • Standards: Compliant with GB/T 17656, EN 13986, AS 6669
Competitive Advantages

Our plywood utilizes calibrated cores and high-weight phenolic film to maximize reuse cycles, offering better ROI than standard panels. With strict control over veneer quality and glue spread, we ensure consistent flatness and strength for demanding applications like bridge decks and shear walls, backed by full traceability and export packaging.

Specifications & Features
Item Specification & Features
Product Name Film Faced Plywood
Core Material Poplar/Birch/Eucalyptus/Combine
Color of film faced paper Brown/Red/Black/Customized Pattern
Glue Melamine glue/Phenolic glue/MR Glue
Size(mm) 1200×1800, 1200×2400, 1220×2440, 1250×2500, etc.
Length (width) Tolerance +/-2mm
Thickness(mm) 8-30mm
Thickness tolerance +/-0.5mm
Density 550-770kg/m³
Number of Layers from 5 up to 21 depending on thickness
Processing of edge waterproof paint in different color
Moisture Content 6-12%
Manufacturing Process Multiple pressing methods including one-time hot pressing, two-times pressing, three-times pressing, and recycling film faced plywood insertion/finger connection
1250*2500 Birch Film Faced Plywood Waterproof Heavy Duty Plywood Weather Resistant 0
Application Scope
  • Construction Industry: Concrete pouring molds for high-rise apartments, commercial buildings, villas, bridges, hospitals, schools
  • Outdoor Stage: Custom anti-slip surface for various outdoor stage constructions
  • Goods Shelves and Box Type Vehicle Flooring: Waterproof, wear-resistant applications in warehouses, railway freight cars, and truck floors
Our Services
  • Consulting Services: Product recommendations based on usage scenarios for cost savings
  • Product Supporting Services: Professional calculation of required accessories for concrete pouring projects
  • Product Quality Inspection: Individual inspection with non-conforming products removed
  • After Sales Service: Immediate response and problem resolution
Frequently Asked Questions
  • How to get a sample? Contact via WhatsApp, WeChat, or email with requirements for sample confirmation and mailing
  • Are you a trading company or manufacturer? Subsidiary foreign trade company of group with 20+ years production experience
  • How to get quotation? Provide detailed product specifications and quantity for accounting quotation
  • How long is your delivery cycle? 5 days standard, 10-15 days for fully customized production
  • What is the payment method? T/T 30% deposit before manufacture, 70% against B/L Copy, or L/C
  • What's your quality guarantee? 100% quality guarantee with responsibility for any quality problems
1250*2500 Birch Film Faced Plywood Waterproof Heavy Duty Plywood Weather Resistant 1
