Tube And Clamp Scaffold
Created with Pixso.

Stable Tube And Clamp Scaffold Heavy Duty Ship Building Scaffolding Customized

Stable Tube And Clamp Scaffold Heavy Duty Ship Building Scaffolding Customized

Brand Name: WKS
MOQ: 200/ Set
Price: US $1.00 - 2.00/ Set
Payment Terms: T/T
Supply Ability: 1000 piece in 10 days
Detail Information
Product Description
Detail Information
Place of Origin:
Hebei,China
Certification:
ROHS
Product Name:
Tube And Clamp Scaffold
Material:
Steel
Surface Treatment:
Hot Dip Galvanized Or PVC Coated
Design Style:
Industrial
Colour:
Customer's Request
Size:
3.56 Kg/m -4.37 Kg/m
Advantage:
Stable
Packing:
37 Or 61 Pieces/bundle.
Keyword:
Quick Clamp Pipe Fittings
Usage:
Buidling Constrcution
Packaging Details:
Bundled / Tied in bundles/Optimization of container loading
Highlight:

Stable Tube And Clamp Scaffold

,

Heavy Duty Ship Building Scaffolding

,

Ship Building Scaffolding Customized

Product Description
Heavy Duty Tube And Clamp Support Scaffold For Shipbuilding
Tube and Clamp Scaffold (also called tubular scaffolding) is a traditional yet highly versatile system built from steel tubes and forged clamps. It is the go-to choice for complex construction sites requiring custom shapes, high load capacity, and adaptability to irregular structures. Unlike modular systems, it offers unlimited configuration possibilities for industrial maintenance, shipbuilding, and complex facade projects.
Key Features & Functions
  • Unmatched Flexibility: Assemble any shape (round, straight, angled) to fit unique project geometries where standard frames fail.
  • Heavy-Duty Safety: Drop-forged steel clamps and high-strength tubes provide superior structural integrity for heavy loads and demanding environments.
  • Cost-Effective: Lower initial investment compared to system scaffolding, ideal for long-term projects and irregular access requirements.
Technical Parameters
  • Material: High-strength steel tubes, hot-dip galvanized for corrosion resistance.
  • Tube Size: Standard 48.3mm OD (or 2-inch), lengths 1m to 6m.
  • Clamps: Drop-forged fixed clamp (90°), swivel clamp (any angle), and beam clamp.
  • Standards: Compliant with EN74, BS1139, OSHA safety standards.
Competitive Advantages
Our system offers full compatibility with existing tubular setups, reducing replacement costs. With a complete range of accessories and third-party certified components, it ensures on-site safety and long-term ROI for contractors handling non-standard construction challenges.
Steel Tube Specifications
Stable Tube And Clamp Scaffold Heavy Duty Ship Building Scaffolding Customized 0
Execution Standard Tube Diameter Tube Wall Thickness Tube Weight Tube Length Zinc Content
EN39 48.3mm 3.2mm 3.56kg/m 0.3-6.3m ≥40 microns
JGJ130 48.3mm 3.6mm 3.97kg/m 0.3-6.3m ≥40 microns
EN74 48.3mm 4mm 4.37kg/m 0.3-6.3m ≥40 microns
Steel Tube Specifications: EN 39/BS 1139 / ASTM A513-07 standards, Q235 or Q345 steel material, hot dip galvanized or PVC coated surface treatment
British Type Couplers
Double Coupler
Stable Tube And Clamp Scaffold Heavy Duty Ship Building Scaffolding Customized 1
Types Size(mm) Weight
Forged British Type 48.3x48.3 1.05KG
Connects two steel tubes that intersect vertically, relying on friction force between coupler and steel tube to transfer load.
Swivel Coupler
Stable Tube And Clamp Scaffold Heavy Duty Ship Building Scaffolding Customized 2
Types Size(mm) Weight
Forged British Type 48.3x48.3 1.25KG
Connects two steel pipes that intersect at any angle.
Sleeve Coupler
Stable Tube And Clamp Scaffold Heavy Duty Ship Building Scaffolding Customized 3
Types Size(mm) Weight
Forged British Type 48.3x48.3 0.95KG
Connects and extends the length of two steel pipes.
Japanese Type Couplers
Double Coupler
Stable Tube And Clamp Scaffold Heavy Duty Ship Building Scaffolding Customized 4
Types Size(mm) Weight
Pressed Japanese type 48.6*48.6 0.55KG
Connects two steel tubes that intersect vertically, relying on friction force between coupler and steel tube to transfer load.
Swivel Coupler
Stable Tube And Clamp Scaffold Heavy Duty Ship Building Scaffolding Customized 5
Types Size(mm) Weight
Pressed Japanese type 48.6*48.6 0.58KG
Connects two steel pipes that intersect at any angle.
Sleeve Coupler
Stable Tube And Clamp Scaffold Heavy Duty Ship Building Scaffolding Customized 6
Types Size(mm) Weight
Pressed japanses type 48.6*48.6 0.60KG
Connects and extends the length of two steel pipes.
Chinese Type Couplers
Double Coupler
Stable Tube And Clamp Scaffold Heavy Duty Ship Building Scaffolding Customized 7
Types Size(mm) Weight
Cast steel Chinese Type 48.3x48.3 1KG
Connects two steel tubes that intersect vertically, relying on friction force between coupler and steel tube to transfer load.
Swivel Coupler
Stable Tube And Clamp Scaffold Heavy Duty Ship Building Scaffolding Customized 8
Types Size(mm) Weight
Cast steel Chinese Type 48.3x48.3 1KG
Connects two steel pipes that intersect at any angle.
Sleeve Coupler
Stable Tube And Clamp Scaffold Heavy Duty Ship Building Scaffolding Customized 9
Types Size(mm) Weight
Cast steel Chinese Type 48.3x48.3 1KG
Connects and extends the length of two steel pipes.
Frequently Asked Questions
Are you a trading company or a manufacturer?
We operate as a trading company for export business, with ownership of a production base operating for over 20 years, specializing in templates and scaffolding related products.
What do you do?
We provide professional implementation solutions, high-quality products, and efficient technical support services in templates and scaffolding.
Do you provide samples? Is the sample chargeable or free?
Yes, we provide samples. Customers are responsible for shipping costs.
How to get quotation?
Provide a required list with product quality, specifications, and quantity details, or supply construction drawings for our engineers to calculate material requirements and provide quotation.
How long is your delivery cycle?
Standard delivery is approximately 5 days. Fully customized production typically requires 10-15 days.
What is your terms of payment?
T/T 30% deposit payment before manufacture, with 70% balanced payment against B/L Copy, or L/C.
