Commercial Film Faced Plywood 18mm 4x8 Feet Plywood Reusable For Construction

Commercial Film Faced Plywood 18mm 4x8 Feet Plywood Reusable For Construction

Brand Name: WKS
MOQ: US $7.50 - 10.80/ Piece
Price: US $55.00 - 70.00/ Square Meter
Payment Terms: T/T
Supply Ability: 1000 piece in 10 days
Detail Information
Place of Origin:
Hebei,China
Certification:
ROHS
Product Name:
Film Faced Plywood
Moisture Content:
6-12%
Material:
Plywood
Color:
Customized Color
Type:
Wall Form
Usage:
Concorete Formwork
Size:
Non-standard:custom-made
Advantage:
Quick Installation
Brand:
Worksun
Keywords:
Commercial Plywood
Packaging Details:
Bundled / Tied in bundles/Optimization of container loading
Highlight:

Commercial Film Faced Plywood

,

18mm 4x8 Feet Plywood

,

4x8 Feet Plywood Reusable

Product Description
Film Faced Plywood Panel Standard Size 4x8 Feet 18mm for Construction
Product Overview

Film Faced Plywood is the industry-standard shuttering panel for high-quality concrete construction. Featuring a hardwood core bonded with waterproof phenolic glue and overlaid with a durable phenolic film, it is engineered for repetitive use in demanding applications like high-rise buildings, bridges, and tunnels. It delivers a smooth concrete finish and outperforms traditional plywood in harsh weather conditions.

Features & Benefits
  • High Reusability & Durability: The phenolic film and WBP glue provide exceptional resistance to moisture, abrasion, and chemicals, allowing for 15-30+ reuse cycles depending on core material
  • Superior Concrete Finish: The ultra-smooth film surface ensures easy demolding and produces a uniform, high-quality concrete surface, minimizing the need for remedial plastering work
  • Structural Strength & Stability: High modulus of rupture and elasticity provide reliable support for heavy wet concrete loads without bending or warping, ensuring dimensional accuracy
  • Waterproof & Weather Resistant: Sealed edges and waterproof construction prevent delamination and swelling, making it suitable for outdoor storage and use in humid environments
Key Specifications
  • Standard Size: 1220×2440mm, 1250×2500mm (Custom sizes available)
  • Thickness: 12mm, 15mm, 18mm, 21mm
  • Core Material: Poplar, Birch, Eucalyptus, or Combi Core
  • Film Color: Black, Brown, Red, Green (Phenolic or PP Film)
  • Glue Type: WBP Phenolic (Weather & Boil Proof)
  • Reuse Cycles: 10-30+ times
Competitive Advantages
  • Cost Efficiency: Offers a lower cost-per-pour than steel formwork and significantly higher reusability than standard plywood
  • Versatility: Available in various grades to suit different project budgets and requirements
  • Proven Performance: Widely trusted by contractors globally for consistent quality and ease of handling
Technical Specifications
Item Specification & Features
Product Name Film Faced Plywood
Core Material Poplar/Birch/Eucalyptus/Combine
Color of film faced paper Brown/Red/Black/Customized Pattern
Glue Melamine glue/Phenolic glue/MR Glue
Size(mm) 1200×1800, 1200×2400, 1220×2440, 1250×2500, etc.
Length (width) Tolerance +/-2mm
Thickness(mm) 8-30mm
Thickness tolerance +/-0.5mm
Density 550-770kg/m³
Number of Layers from 5 up to 21 depending on thickness
Processing of edge waterproof paint in different color
Moisture Content 6-12%
Manufacturing Process Multiple pressing methods including one-time hot pressing, two-times pressing, three-times pressing, and recycling film faced plywood insertion
Application Scope
  • Construction Industry: Used as molds for concrete pouring in high-floor apartments, commercial buildings, villas, bridges, hospitals, schools, and various construction buildings
  • Outdoor Stage: Customizable anti-slip facial mask paper for various types of outdoor stage construction
  • Goods Shelves and Box Type Vehicle Flooring: Widely used in warehouses (shelves), railway freight cars, and truck floors and sidewalls due to waterproof, wear-resistant, and pressure resistant properties
Commercial Film Faced Plywood 18mm 4x8 Feet Plywood Reusable For Construction 0
Our Services
  • Consulting Services: Recommendation of most suitable and cost-effective products based on customer usage scenarios
  • Product Supporting Services: Professional team helps calculate required accessories for concrete pouring projects
  • Product Quality Inspection: Each product undergoes quality inspection with non-conforming products removed
  • After Sales Service: Immediate response and problem resolution from our sales team
Frequently Asked Questions

How to get a sample? Is the sample chargeable or free?
Contact us via WhatsApp, WeChat, or email with your requirements. We will confirm accurate requirements before mailing samples.

Are you a trading company or a manufacturer?
We are a subsidiary foreign trade company of a group company with two major production bases specializing in formwork and scaffolding products for over 20 years.

How to get quotation?
Provide us with required list including product quality, specifications, and quantity for accounting quotation.

How long is your delivery cycle?
Standard delivery: around 5 days. Custom production: 10-15 days.

What is the payment method you require?
T/T 30% deposit before manufacture, 70% balanced payment against B/L Copy, or L/C.

What's your quality guarantee?
100% quality guarantee - we take full responsibility for any quality problems.

Commercial Film Faced Plywood 18mm 4x8 Feet Plywood Reusable For Construction 1
